Overview

Basic Info.

Model NO.	DP6000iL
Weight	75kg
Warranty	5 Years
Color	Black
Certificates	CE, RoHS, EU V
Battery Is Removable	Yes
Charging Type	AC Outlet, DC, Solar
Cell Type	Life Po4
Display	with Display
LED Lighting	with LED Lighting
Socket Type	All
Transport Package	Polybag+EPE Foam+Carton
Specification	75*56*63 CM
Trademark	DRIVELONG
Origin	China
HS Code	8504401990
Production Capacity	50000sets/Year

Packaging & Delivery

Package Size75.00cm * 63.00cm * 58.00cm Package Gross Weight75.000kg

Product Description

1.Built in 5376Wh LiFePO4 battery with professional solar bidirectional inverter, support for 6kW charging and discharging.
2.Support various quick charging methods such as utility, solar, EV charger and wind turbine.
3.Up to 31 extra batteries can be connected for expansion, with a total capacity of 172kWh.
4.Built in maximum 450V rooftop PV MPPT controller, can be used as an integrated household photovoltaic energy storage power station.
5.Unprecedented portability with "zero gravity".
6.Built in minimum 10V MPPT controller for portable solar panel, can be used as a portable solar power station.
7.IP23 protection grade & dustproof kit.
8.Multiple system security protection.
9.The intelligent control and monitor by smartphone APP.
10.Conformed to EU and US security certification.
11.Better quality with 5 years nationwide warranty.
ADD-ONS(Sold Separately) Product Description Our Advantages Product Parameters

AC Output	Rated Power	6000VA @220~240V, 5000VA @100~120V
	Peak Power	12000VA / 10000VA
	Output Waveform	Pure-Sine Wave, THD<3%
	Rated Voltage	100/110/120V, 220/230/240V
	Rated Frequency	50/60Hz
DC Output	Cigarette Lighter Port	12V/10A
	5521 Port	12V/6A
	USB	5V/3.1A, QC3.0(5V/3.4A, 9V/2A, 12V/1.5A)
	Type-C	PD60W/100W(5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A, 20V/5A)

AC	Wall Outlet & AC Generator	220~240VAC Output	100~250VAC@Appliances Mode, 180~250VAC@UPS Mode 16A MAX, Max. 3600W, 2 hours fully charged
		100~120VAC Output	90~130VAC 16A MAX, Max. 1800W, 4 hours fully charged
High-voltage Solar	MPPT Control System	220~240VAC Output	80~450VDC 27A MAX, Max. 6000W, 1 hours fully charged Solar energy can feed to grid
		100~120VAC Output	120~450VDC 22A MAX, Max. 5000W, 1.5 hours fully charged Solar energy can feed to grid
Low-voltage Solar(1)	MPPT Control System		10~150VDC, Max. 2000W, 3 hours fully charged
EV Charger(1)	Mennekes IEC 62196(Type 2) SAE J1772(Type 1) GB/T 20234	220~240VAC Output	100~250VAC@Appliances Mode, 180~250VAC@UPS Mode 32A MAX, Max. 6000W, 1 hours fully charged
		100~120VAC Output	90~130VAC 50A MAX, Max. 5000W, 1.5 hours fully charged
Wind(1)	3AC Port		3AC 48~60V, Max. 2000W, 3 hours fully charged

Extra Battery	51.2V 5376Wh, Up to 31 units(Total 172kWh)
SE Series Smart Inverter Generator	100~240VAC, 1.8~3.7kW
DW Series Wind Turbine	48VAC, 600~2000W
DSF Series Solar Panels	41V~82V, 200~600W, IP66
DVC Series EV AC Charger	100~240VAC, 25~50A MAX
